| Model |
RF-640 8 Colour |
| Printing technology |
Piezoelectric inkjet |
| Acceptable media |
Width |
259 to 1625 mm (10.2 to 64 in.) |
| Thickness |
Max. 1.0 mm (39 mil) with liner |
| Roll outer diameter |
Max. 210 mm (8.3 in.) |
| Weight |
Max. 40 kg (88 lb) |
| Core diameter*1 |
76.2 mm (3 in.) / 50.8 mm (2 in.) |
| Media take-up system |
Max. 210 mm (8.3 in.) outer diameter / Max. 50 kg (110 lb) weight |
| Printing width*2 |
Max. 1615 mm (63.6 in.) |
| Ink |
Type |
ECO-SOL MAX 3 500 ml cartridges, INKU EGS 500 ml cartridges |
| Colours |
8 colours (Cyan, Magenta, Yellow, Black, Light Black, Red, Green, Orange) |
| Print resolution (dots per inch) |
Max. 1440 dpi |
| Distance accuracy*3 |
Error of less than ± 0.3 % of distance travelled, or ± 0.3 mm, whichever is greater. |
| Media heating system*4 |
Print heater set temperature: 30 to 45°C (86 to 113°F)
Dryer set temperature: 30 to 50°C (86 to 122°F) |
| Connectivity |
Ethernet (10 BASE-T / 100 BASE-TX, automatic switching) |
| Power-saving function |
Automatic sleep feature |
| Power requirements |
AC 100 to 120 V ± 10% 8.1A, 50/60 Hz or AC 220 to 240 V ± 10% 4.1A, 50/60 Hz |
| Power consumption |
During operation |
Approx. 1070 W |
| Sleep mode |
Approx. 31 W |
| Acoustic noise level |
During operation |
62 dB (A) or less |
| Sleep mode |
49 dB (A) or less |
| Dimensions (with stand) |
2575 (W) x 795 (D) x 1270 (H) mm (101.4 x 31.1 x 50 in.) |
| Weight (with stand) |
140 kg (309 lb) |
| Environment |
Power on *5 |
Temperature: 15° to 32°C (59° to 90°F) (20°C [68°F] or more recommended) /Humidity: 35 to 80%RH (no condensation) |
| Power off |
Temperature: 5° to 40°C (41° to 104°F) / Humidity: 20 to 80%RH (no condensation) |
| Included items |
ErgoSoft Roland Edition 2 SPECIAL PLUS RIP Software, exclusive stands, power cable, media clamps, media holder, replacement blades for separation knife, User’s Manual, etc. |
