| Max rollers speed | 5,6- 16 m/min |
| Max paper width (mm) | 520 mm (glue application only) |
| Material thickness** | gluing only :80-300 gsm or up to 5mm (with optional rigid boards module) turning in: 80-250 gsm |
| Heating time | ~15 min |
| Temperature (°C) | 0-95 degrees (possible to work with cold glue with 0 degrees temperature ex. when making inner paper) |
| Glue tank capacity | 4l |
| Glue type*** | Organic glue (*** possible to work with cold glue with 0 degrees temperature ex. when making inner paper) |
| Productivity* | ~ 240-300 pcs/ hour |
| Cover material type | Paper, textile, laminated paper, photopaper, eco leather, pvc, polyurethane |
| Min size of open case | 145 x 145 mm |
| Max size of open case | 480 x 770 mm – edge turn in 20mm 500 x 800 mm edge turn in 10 mm |
| Board thickness** | 1,5 mm- 4 mm |
| Spine width | 1-100mm |
| The minimum distance between boards when producing covers without a spine | 4 mm |
| Overlap covering material | 10-20 mm |
| Vacuum on table | YES (integrated air blower) |
| Power supply | 3 Ph, 400V/50Hz |
| Power installed | 3,8 kW (heater switched on); 0,8 kW (heater switched off). |
| Dimensions | 299cm x 194 x 117 cm – min door width. 135cm |
| Weight (kg) | 900 kg |
| Air compressor | Not required |
